Motherboard chip

B85

CPU

Intel Xeon E5 LGA2011-V3 pin CPU (with DDR3 memory controller)

For example: E5-2629v3/2666v3/2673v3/2676v3/2678v3/2696v3/2684v4/2696v4, etc.

memory

4*DDR3 DIMM quad-channel, 1066/1333/1600/1866MHz(MAX), with maximum support of 128G (32G*4).

Cunzhu

2*M.2 slot (NVME protocol: pcie 3.0x4); 6*SATA interface (SATA3.0*4+SATA2.0*2)

Display interface

/

network

1*RJ45 interface

Network card chip

Realtek gigabit network card chip

PS/2

1 KB interface and 1 MS interface.

audio frequency

1*Line out，1*MIC In，1*Line in； 1*F_Audio built-in pin

Audio chip

Realtek HD audio chip

Usb interface

IO interface: 2*USB3.0, 6*USB2.0;

Built-in pins: 1 set of USB2.0 pins (2 USB2.0 ports can be extended); 1 set of USB3.0 pins (2 USB3.0 ports can be expanded)

PCIE

PCIE1/3 :PCIE X16 3.0 slot (from CPU)

PCIE2/4:PCIE X1 2.0 slot (from PCH)

Functional pin

1*FPANEL panel pin; 1*4Pin CPU fan; 2*3Pin+1*4Pin SYS fan; 1*JCMOS pin; 1*TPM pin; 1*COM pin

Power input

24Pin+8Pin ATX power socket

product size

216 x 283mm, 6-layer PCB
